STANDARD 1" THICK INSULATING CORE FITS SERIES 77, 77XL, 808 AND 303
VIC™ COUPLINGS INSULATION
STANDARD OPERATING
TEMPERATURE RANGE
DRAGON JACKET - STANDARD
-60°F to 275°F
DRAGON JACKET - HIGH TEMPERATURE
-40°F to 350°F
STATIC R-VALUE
6.25 PER INCH
STATIC K-FACTOR
0.174 BTU-IN/HR-FT2-F
STANDARD COLORS
High Pigment Black
Silver
Custom on Request
INDUSTRIES SERVED
Mining
Chemical / Petrochemical
Food & Beverage
Construction
Agriculture
Energy / Power
Water / Wastewater
5-Year Limited Product Warranty. FDA Approved for Incidental Food Contact. Made in the USA.
FEATURES
Fully Encapsulated
Durable / Impact Resistant
High Tensile
Removeable / Reusable
Waterproof
Chemical Resistant
Lightweight
Interlocking Panels
Integrated Drip Edges
BENEFITS
Eliminates CUI
Engineered Solutions
Faster, Safer Installation
Thermal Stability
Energy Efficient
Operationally Efficient
Withstands Harsh Environs
Lower TCO
20+ Year Lifespan
| Size | ID | OD | Length | Part # | Description |
|---|---|---|---|---|---|
| 1.5″ | 2.5 | 8.25 | 2.375 | VCP-2.5×8.25 | VIC™ STYLE COUPLING 2.5″ ID x 8.25″ OD |
| 2″ | 2.75 | 8.75 | 2.375 | VCP-2.75×8.75 | VIC™ STYLE COUPLING 2.75″ ID x 8.75″ OD |
| 3″ | 4 | 10.5 | 2.625 | VCP-4×10.5 | VIC™ STYLE COUPLING 4″ ID x 10.5″ OD |
| 4″ | 5 | 12.25 | 2.875 | VCP-5×12.25 | VIC™ STYLE COUPLING 5″ ID x 12.25″ OD |
| 6″ | 6 | 16.5 | 4.375 | VCP-6×16.5 | VIC™ STYLE COUPLING 6″ ID x 16.5″ OD |
| 8″ | 9 | 18.5 | 5.25 | VCP-9×18.5 | VIC™ STYLE COUPLING 9″ ID x 18.5″ OD |
| 10″ | 11.25 | 21 | 5.25 | VCP=11.25×21 | VIC™ STYLE COUPLING 11.25″ ID x 21″ OD |
| 12″ | 13.25 | 24 | 5 | VCP-13.25×24 | VIC™ STYLE COUPLING 13.25″ ID x 24″ OD |
COMPARE DRAGON JACKET TO OTHER INSULATION OPTIONS
Dragon Jacket Insulation™ |
Fibrous Insulation |
|
|---|---|---|
5-Year Warranty |
✔ |
✘ |
Waterproof |
✔ |
✘ |
CUI Resistant |
✔ |
✘ |
95+ MPH Wind Resistant |
✔ |
✘ |
Extended 20+ Year Life |
✔ |
✘ |
Impact Resistant |
✔ |
✘ |
Uninstall, Inspect, Re-Install |
✔ |
✘ |
UV Resistant |
✔ |
✘ |
